Netflow
Configure Netflow Log Source with observIQ


Supported Versions
Netflow versions
- v5
- v9
- IPFIX
Prerequisites
Forward Netflow data to port 2055 on the observIQ agent.
Configuration
Option | Description |
---|---|
Listen Address | Use this field to verify the path to the Listen Address, an address in the form of ': '. The default is '0.0.0.0:2055' |
Netflow Version | The version of Netflow (v5, v9, or IPFIX). |
Sampling Drop Rate | The probability an entry is dropped. A value of 1.0 will drop 100% of matching entries, while a value of 0.0 will drop 0%. |
Log Types
Types |
---|
netflow |
Dashboards
Users can configure dashboards using visualizations. More information can be found on our visualizations and dashboards page.
Advanced
For more information on the advanced configuration capabilities, see our detailed plugin guide here.
